Linear Screening Machine (LSM)

PDF-Download Linear Screening Machine

The LSM screens solid mixtures according to their particle size.

UMS has developed own Linear Screening Machines, since no product was available on the market fulfilling our requirements at the time.

The LSM can be equipped with three stacked screen inserts resulting in four screen cuts. A wide range of different screen inserts are available.

The LSM is driven by two counteracting unbalance motors vibrating the unit with the firmly tensioned screen inserts. The linear vibration exerts force impulses on the material, which convey it in throwing movements into the direction of the screen discharge. Depending on the particle size, the screening material passes through the different screen inserts, and is fractioned into the corresponding particle size divisions.

UMS optimizes and adds the LSM to existing systems also not limited to selection, positioning and integration therein.

The LSM is available in different sizes. In addition to the LSM, UMS developed further particularly very special screening solutions for materials difficult to screen with standard machines e. g. E-scrap, material containing wires.

If you request an offer or want to purchase a Linear Screening Machine (LMS) directly, please fill out the form under Contact.

Other dimensions are available on request. We offer the LSM as single machines without or with the supporting steel structure executed as standard or tailor-made to your requirements. Extension of or integration into your operating system is also possible.

Linear Screening Machine (LSM) | Linearsiebmaschine 01
Linear Screening Machine (LSM) | Linearsiebmaschine 02
Linear Screening Machine (LSM) | Linearsiebmaschine 03
Linear Screening Machine (LSM) | Linearsiebmaschine 04
